Electron Security Audit — a real sample, verifiable evidence
Target audited: draw.io Desktop v32.4.1 (
drawio-amd64-32.4.1.deb, 116 MB, GPL-3.0) Public sample · produced 2026-10-16 with our own engine · no client involved — this is the demonstration piece Turnaround: 48 h standard (this one took a day) · Evidence chain: 3 evidence IDs + SHA-256This is the exact structure of what we ship: the report, the template, the authorization, the proforma and the evidence bundle — published in full so you can judge it before talking to anyone. Every claim below carries a cryptographic evidence ID, and what we could not determine is declared explicitly. That section is the product.
TL;DR
| Overall status | 🟢 No critical findings — secure baseline, with two coverage items to watch |
| Dependencies (SBOM) | 82 packages with versions (9 direct) |
| CVE cross-check | 0 of 5 checked CVEs affect this build (Electron 44.7.0, electron-updater 6.8.9) |
| Electron windows | 5 BrowserWindow → 4/4 verified (contextIsolation:true, nodeIntegration:false), 1 dynamic → unverifiable |
| IPC surface | 35 operations · 28 literal channels · 29 main handlers |
contextBridge |
only 2 APIs / 6 members exposed (tight, purpose-scoped) |
| Secrets in scope | 0 (5 credential pattern families, zero matches) |
| Honesty metric | 92,468 unknowns explicitly declared + 7 limitations with named files |
Why this repo exists
Desktop apps ship thousands of transitive dependencies nobody inventories. This sample shows what you get when an Electron/JS build is audited statically, reproducibly, and honestly:
- Verifiable — every observation has an
evidence_id: the SHA-256 of the canonical semantic projection of the evidence document, recomputable withevidence/verify-evidence.mjs(no dependencies, plain Node). The artifact hash is checked against the project’s own published hash, and you can re-run the whole pipeline for free. - Honest — limitations are a first-class section, not a footnote. Unresolvable things are listed as unresolvable. 92,468 unknowns are counted and indexed, not swept away.
- Legal by construction — only open-source / self-owned / written-authorized targets. Never DRM, anti-cheat, license bypass, or third-party production systems.
Findings at a glance
1. SBOM & dependency hygiene
| Finding | Detail | Level |
|---|---|---|
| 82 packages, versions pinned | from every package.json manifest inside the app.asar |
🟢 |
| 9 direct dependencies | electron-updater · electron-store · electron-log · @cantoo/pdf-lib · … |
🟢 |
| 3 duplicated families | debug (2.6.9 and 4.4.3) · ms (2.0.0 and 2.1.3) · semver (7.7.4 and 7.8.5) |
🟡 |
| Stale transitive line | debug@2.6.9 (2017-era) still shipped |
🟡 |
2. CVE cross-check (NVD / GitHub Advisories / GitLab GLAD / Snyk — queried 2026-10-16)
| CVE | Affects | Installed | Status |
|---|---|---|---|
| CVE-2024-39698 (electron-updater sig bypass) | < 6.3.0-alpha.6 |
6.8.9 | ✅ not affected |
| CVE-2026-54673 (credential header leak on redirect) | builder-util-runtime < 9.7.0 |
9.7.0 | ✅ fixed — sitting exactly on the patch floor |
CVE-2026-54672 (AppImage LD_LIBRARY_PATH) |
build tooling < 26.15.0 |
26.17.0 | ✅ fixed (build-time) |
| CVE-2026-102672 (Electron, Squirrel.Mac race, macOS) | ≤39.8.x / ≤41.10.4 / <42.0.0-beta.2 |
44.7.0 | ✅ not affected |
| CVE-2026-70604 (Electron CORS on custom schemes) | ≤39.8.9 / ≤40.9.3 / ≤41.4.0 / <42.0.0 |
44.7.0 | ✅ not affected |
Scope: 5 relevant candidates, not an exhaustive NVD sweep of all 82 versions — declared in §6.7 of the report.
3. Electron security architecture (main process, complete run)
| Vector | Result |
|---|---|
contextIsolation |
✅ true in 4/4 windows with literal options |
nodeIntegration |
✅ false in 4/4 |
webSecurity / webviewTag |
✅ true / ✅ false in 4/4 |
sandbox |
🟠 explicitly true in only 1/5 windows — the rest don’t declare it, and we don’t assume defaults |
1 window (electron.js:565) |
🟠 options built dynamically → not statically verifiable |
contextBridge |
✅ tight: electron{listenOnce, registerMsgListener, request, sendMessage} + process{type, versions} — no require, no fs, no raw ipcRenderer |
| IPC | 28 literal channels (file ops, window, updates, config) + 3 dynamic (action) · 0 unpaired literal transmissions |
| Sender validation | 🟠 2 candidates observed among 29 handlers (enforcement: unknown) — absence of observation ≠ absence of validation |
| Secrets | ✅ 0 matches across 5 credential pattern families |
How it was audited (and why you can trust it)
┌────────────── GITHUB ACTIONS (free, public repo) ──────────────┐
artifact ─▶│ download → SHA-256 vs official Files-SHA256-Hashes.txt ✅ │
(from the │ extract .deb → app.asar │
project's │ REA 6.5.0: analyze-javascript-application (full asar) │
release) │ REA 6.5.0: analyze-javascript-application (main process) │
│ Ghidra 12.1.4: binary_overview (ELF x86_64) │
└──────────────┬─────────────────────────────────────────────────┘
▼
evidence (kilobytes) + evidence IDs + hashes
- The heavy lifting runs in the cloud (the 116 MB artifact, 543 MB Ghidra) — clients’ software never touches third-party SaaS; for real engagements the analysis runs on our private runner or on yours.
- The whole pipeline is workflow
rea-audit.yml— reproducible at zero cost.
Runs
| Run | Scope | Result |
|---|---|---|
38856900076 |
full app.asar + Ghidra native |
⚠️ partial (honest timeout at 300 s / 1 GB heap on app.min.js) + ✅ native complete |
38858685634 |
main process only | ✅ complete in 5 s |
Evidence chain
| Operation | evidence_id |
|---|---|
| JS analysis — full asar | ev_a94efae81586d359238a5eb1cd34b9a9ed8da7748c3f9a86d4757fe855435ca8 |
| JS analysis — main process | ev_f0e4202c3b188da10f4be9b3693006b0ba64e3483e7ea100916e388dd413fc2e |
Ghidra binary_overview — native |
ev_9ec17cfca1a869df4352fd6e5db03285c014f0efc2024a30ec924c337c7a22f0 |
| Artifact | SHA-256 |
|---|---|
drawio-amd64-32.4.1.deb |
f4455b3bba3d3b539c3cd069218fc64f0462b1b01610fe8d11acc3ca8566f32b ✅ matches official hash |
app.asar (run 1 root) |
e64b9650c0b8241ca9a7d33b56386a385bceee63270cec701d3a467347b697e6 |
src/main dir (run 2 root) |
04b32cf796534f828ddb3b57568be1e7e1be27f9f8d43debc924af49b5d19596 |
Reproduce it yourself:
curl -LO https://github.com/jgraph/drawio-desktop/releases/download/v32.4.1/drawio-amd64-32.4.1.deb
sha256sum drawio-amd64-32.4.1.deb # → f4455b3b…
rea analyze-javascript-application <target> --json
Raw evidence bundle: evidence/ · summary index: evidence/evidence-summary.json
What we deliberately do NOT claim
Most due-diligence reports hide their blind spots. We publish them:
- Source analysis was interrupted by explicit limits (300 s, 1 GB heap) on the huge minified
bundle
app.min.js— the run stopped, and that’s recorded, not hidden. - Inline JavaScript in
dropbox.html,github.html,gitlab.htmlwas not analyzed (named in §6.1). - 92,468 unknowns are indexed with IDs across 12 fact families — all
partial. - Static analysis: nothing was executed; runtime behavior, defaults, and enforcement remain unproven.
- CSP and the renderer HTML live outside this scope — not evidenced ≠ not present.
- Only the
.debartifact was audited (AppImage/Windows/macOS builds may differ). - The Electron version (44.7.0) comes from the tag’s lockfile — not read from the binary itself.
Full section: docs/audit-report-drawio-32.4.1.md §6.
The service — what you get
Entry package: flat 150 USDT (USDT or USDC, TRC-20 or BEP-20) · delivered in 48 h · your artifact never touches third-party SaaS: the analysis runs on our private runner or yours. (This public sample ran in a public CI runner — the target is public software.)
Our three guarantees: ① Deadline — if it is not delivered in 48 h, you get 100 % back. ② Accuracy — if a finding is contradicted by the source, we re-render it or credit you 100 %; the evidence IDs make that checkable. ③ Privacy — static, read-only, on a private runner, artifact deleted after delivery.
| # | Deliverable |
|---|---|
| 1 | SBOM — full dependency tree with versions |
| 2 | Risk — vulnerable / stale dependencies, CVE cross-check |
| 3 | Exposure — Electron vectors: contextIsolation, nodeIntegration, sandbox, CSP, IPC channels |
| 4 | Secrets — embedded credentials in the bundle (presence only, never extracted) |
| 5 | Limits & unknowns — the honest section (see above) |
| 6 | Evidence IDs — third-party verifiable proof for every claim |
Not included (available in higher tiers): remediation · source review · dynamic analysis · native binary deep-dive (Ghidra) · infrastructure audit · SLA.
| Package | Price | Scope |
|---|---|---|
| Entry | 150 USDT | everything above, 48 h |
| Standard | 600 USDT | + prioritized remediation, 5 days |
| Pro | 2,500 USDT | + deep audit + guided remediation, 2 weeks |
| Enterprise | 5,000–15,000 USDT | + native analysis (Ghidra) + ongoing support |
How to start
① You send the artifact + sign the authorization form → docs/engagement-authorization.md
② You pay 150 USDT (or USDC; TRC-20 / BEP-20) — proforma: docs/payment-proforma.md
③ We deliver the report ≤ 48 h + evidence IDs → docs/audit-report-drawio-32.4.1.md (format of what you receive)
Contact: florito64.1@gmail.com — email is the best channel for an engagement: we can move the
whole conversation to a private channel from there. (Use the repo’s issue tracker only for
questions about the public report or the sample evidence bundle.)
Documents
Scope & legal
- Targets are open-source (public license), self-owned, or covered by written authorization + NDA only.
- Never: DRM/license circumvention · anti-cheat bypass · authentication bypass · attacks against third-party production systems · cloning proprietary software. Analysis is read-only, static.
- See the REA disclaimer.
- This report is a sample on open-source software (draw.io, GPL-3.0); client reports are private.
Pipeline: REA 6.5.0 + Ghidra 12.1.4 on free GitHub Actions. Report © 2026 — free to share and link with attribution. No warranty; see report §6 (limits).
